Applications |
| |
| "Stronger than steel but lighter than aluminum", an excellent material - TAIRYFIL (Carbon Fiber Yarn) can be widely used for many kinds of fields.
Its main applications are as follows : |
 |
|
|
| 1. |
Sports and Leisure: tennis and badminton rackets, fishing rod, bow, golf shaft, surfboard, ski-board, bicycle, etc. |
 |
| 2. |
Vessels: yacht, reinforcing material for high-speed hull, windsurfing etc. |
|
| 3. |
Electric facility: spare parts for robot, computer, electric blanket, TV antenna, etc. |
|
| 4. |
Industrial use: tank, piping, bearing, CNG tank, roll, electrical generator of wind power, packing, electric blanket etc. |
|
| 5. |
Vehicles: frame, friction lining for automotive brakes, leaf spring, drive shaft, racing car etc. |
|
| 6. |
Medical devices: X-ray film cassette, wheelchair, bed of X-ray diagnostic equipment, etc. |
|
| 7. |
Space and aerial-aviation: satellite, space shuttle, jet aircraft, jet fighter, rocket, C/C disk brake, etc. |
|
| 8. |
Civil engineering: repairing and reinforcing material for bridges, building, etc. |
|
|
|
|
|
|
 |
 |
Safe processing and handling |
|
| 1. |
Operation |
|
TAIRYFIL, a superior conductor, should be kept away from electricity sources in operation. Operating equipment must be completely insulated to prevent shocks caused by the direct contact of TAIRYFIL to electricity. |
| 2. |
Storage |
|
TAIRFYIL is coiled on bobbins and stored in cartons which should not be crashed, or there will be damage to the surface of TAIRYFIL and to later process. |
|
|
Properties |
|
|
Physical
Properties and Technical Data Sheet
| Item |
Number
of
Filament |
Yield
Tex
(g/1000m) |
Tensile
Strength |
Tensile
Modulus |
Elongation
( % ) |
Density
(g/cm2) |
Filament
Diameter |
| Unit |
Ksi |
Mpn |
Msi |
Gpa |
| Fiber
type |
| TC-33 |
3K |
3,000 |
200 |
500 |
3,450 |
33 |
230 |
1.5 |
1.8 |
7.0 |
| 6K |
8,000 |
400 |
500 |
3,450 |
33 |
230 |
1.5 |
1.8 |
7.0 |
| 12K |
12,000 |
800 |
500 |
3,450 |
33 |
230 |
1.5 |
1.8 |
7.0 |
| TC-35 |
12K |
12000 |
720 |
580 |
4,000 |
35 |
240 |
1.6 |
1.8 |
6.5 |
| 18K |
18,000 |
1000 |
580 |
4,000 |
35 |
240 |
1.6 |
1.8 |
6.5 |
| TC-36 |
3K |
3,000 |
180 |
680 |
4,680 |
36 |
250 |
1.9 |
1.81 |
6.5 |
| 6K |
6,000 |
360 |
680 |
4,680 |
36 |
250 |
1.9 |
1.81 |
6.5 |
| 12K |
12,000 |
720 |
680 |
4,680 |
36 |
250 |
1.9 |
1.81 |
6.5 |
| TC-36S |
18K |
18,000 |
800 |
710 |
4,890 |
46 |
250 |
2.0 |
1.81 |
5.6 |
| TC-42 |
6K |
6,000 |
260 |
710 |
4,890 |
42 |
290 |
1.7 |
1.8 |
7.7 |
| 12K |
12,000 |
520 |
710 |
4,890 |
42 |
290 |
1.7 |
1.8 |
7.7 |
|
|
|
|
|
|
